Highlights
45MP full-frame sensor for ultra-high-resolution mapping
Global mechanical shutter with 1-2000s shutter speed
Seamlessly integrates with Matrice 300 and 350 RTK for geospatial accuracy
Supports Smart Oblique Capture for faster aerial surveys
Detailed Specifications
Zenmuse P1
General
- Compatibility: DJI Matrice 300 RTK, Matrice 350 RTK
- Weight: Approx. 850 g
Camera System
- Sensor: Full-frame CMOS sensor
- Resolution: 45 MP
- Pixel Size: 4.4 μm
- Shutter: Mechanical shutter
Imaging
- Capture Speed: 0.7 seconds per image
- Image Format: JPEG, DNG
Gimbal
- 3-axis stabilized gimbal
Application Scenarios
Zenmuse P1
Features and Performances
High-Resolution Imaging
The Zenmuse P1 captures stunningly detailed 45MP images with its full-frame sensor, providing the clarity and accuracy required for professional photogrammetry applications.
Interchangeable Lenses
The P1 supports interchangeable lenses, allowing users to select the optimal lens for their specific needs and applications.
Mechanical Shutter
The mechanical shutter minimizes distortion and ensures high-quality images, even when capturing fast-moving objects or flying at high speeds.
High Efficiency
The P1’s fast capture speed of 0.7 seconds per image enables efficient data acquisition, reducing flight time and increasing productivity.
Seamless Integration
The Zenmuse P1 seamlessly integrates with the DJI Matrice 300 RTK and M350 RTK platforms, as well as DJI Pilot and DJI Terra software, providing a streamlined workflow for data collection and processing.
